ALINCO DR-138 VHF BASE/MOBILE

200 channel, UHF 60 Watt Transceiver 136 - 174 MHZ - Part 90 Certified

ALINCO’s feature packed Analog VHF Mobile Radio is perfect choice for multiple applications.. The DR-138 radio delivers power and performance in a small package. User-friendly configuration and programmable features make the DR-138 the radio of choice for business and commercial use without compromising higher price

Product Description

The DR-138 is a high technology PLL synthesized radio that delivers power and performance in a small package. User-friendly configuration and programmable features make the DR-138,the radio of choice for demanding operators, both professionals, and amateurs.

Alinco DR-138 VHF Mobile Radio offered by us is designed by using best grade electronic equipment that makes it highly efficient to make a communication channel with two or more receivers by using the set frequency of radio waves. It is small compact box which is provided with a transmitter and a receiver to send or receive signal. This device is also provided with controlling knobs and push buttons to set the frequency, mode of operations and the volume of the system.



Features:

  • 3 Selectable Output Power Levels (VHF 60W /25W/10W, UHF 45W /25W/10W)
  • PC-programmable 200ch memories
  • Alphanumeric name tags
  • Voice Compander (Reduce Noise & enhance audio clarity)
  • Wide variety of selective calling features are built-in:2-Tone, 5-Tone, 50 CTCSS, 114 DCS, 4 Tone-burst tones and DTMF/ANI decode
  • Radio stun/kill/revive functions to protect your communications security
  • Large, bright LCD and easy-to-operate backlit keys
  • Multi-function, backlit microphone enables direct frequency entry & more from keypad
  • Various scan modes, Key lock, Wide/Narrow operations



Specifications
Frequency range
136-174MHz
Transmitting power
10W / 25W / 60W switchable
Operating mode
FM
Channel Spacing2.5 / 5 / 6.25 / 8.33 / 10 / 12.5 / 15/20/25/30/50 kHz
Memory channels
200
Microphone connector
8-pole
Antenna Connection
PL-259 connector
Power supply
13.8 VDC +/- 15% (max. 10A)




Delivery Package:

  • ALINCO DR-138H Transceiver

  • Hand Microphone EMS-74

  • Mobile holder ADFM-78

  • DC cable ADUA-38

  • Instructions

  • Weight: 1.2 kg
