BAOFENG UV-6 Two Way Dual Band Transceiver

BAOFENG UV-6 Two Way 136-174/400-480MHZ UHF/VHF Ham Radio Dual Band Transceiver.3 Scanning Ways (Time, Carrier wave, Search), PTT-ID (Press PTT to transmit code, release PTT to transmit code, or both can transmit code), VOX, FM Radio, Busy Channel Lock, Alarm, TOT (Time-out Timer) Function.

Features:

  • Dual-band handheld transceiver with LCD display function.

  • Commercial FM radio receiver(65MHz~108MHz).

  • Incorporates 105 codes "DCS" and 50 privacy codes "CTCSS" programmable.

  • 6 selectable frequency step(2.5/5/6.25/10/12.5/20/25 KHz)

  • Function VOX(vioce operate transmission).

  • DTMF encoded.

  • Emergency Alarm function.

  • Up to 128 memory channels.


Product Features:

  • Frequency Range: 136-174 / 400-480MHz, Dual Channels Watch, Dual Band.

  • 3 Scanning Ways (Time, Carrier wave, Search), PTT-ID (Press PTT to transmit code, release PTT to transmit code, or both can transmit code), VOX , FM Radio, Busy Channel Lock, Alarm, TOT (Time-out Timer) Function.

  • PC Program, Voice Prompt, DTMF Side Tone, Channel Monitor, High/Low Power Switchover, Chinese/English Switch, Battery Saving, Low Battery Warning, Over Voltage or Low Voltage Protection.

  • High-capacity battery: low self-discharge; no memory effect, high cycle life; with special design, can be used in hot and cold area.




Specifications

Type
Dual-band Transceiver
Brand
BAOFENG
Model
UV-6
Frequency range
U/V: 400-480MHz/136-174MHz
Channel capacity
16
Channel spacing
25.0kHz / 12.5kHz
Frequency stability
±1.5ppm
Working temperature:
20 ~ +60
Antenna impedance
50Ω
Working voltage
3.7V
Battery
1800mAh (Lithium ion battery)
Receiving sensitivity
0.15μV / 0.18μV
Adjacent channel selectivity
65dB / 55dB
Intermodulation Rejection
55dB
Spurious Response
≥60dB
Signal to noise ratio
40dB / 35dB
Rated audio output power
≥600mW
Rated audio distortion
≤5%
