Baofeng UV-8D Transreceiver UHF/VHF

Long Range Walkie Talkie UHF/VHF Dual Band Dual PTT Key Two Way Radio Transceiver with FM radio Each radio comes with a charger, antenna, 2800 mAh Rechargeable Battery and everything you need to get started communicating conveniently at a long range,

 Features:

  • Two-way handheld transceiver.

  • DTMF encoded.

  • 2800mAh Lithium-ion battery with high capacity.

  • Alarm function.

  • Up to 128 memory channels.

  • Dual PTT Key

  • CTCSS/ DCS

  • DTMF Code

  • LED Flashlight


Introduction

The UV-8D is a super long range premium quality featured two way radio and hand held professional grade transceiver with capabilities upto 6 Km. The Audio quality is superb. Each radio comes with a charger, antenna, 2800 mAh Rechargeable Battery and everything you need to get started communicating conveniently at a long range, whether in a recreational context like camping or on site at your business. The UV-8D includes many perks that elevate it above an average Walkie Talkie, such as VOX (Voice Operated Exchange) which makes it unnecessary to push a button to talk, FM radio, Alarm Function, High/Low Power selection, PC Programmable, Built in high illumination LED Flash Light, Dual Band with dual PTT Key etc.




Features:

  • Two-way handheld transceiver.

  • DTMF encoded.

  • 2800mAh Lithium-ion battery with high capacity.

  • Alarm function.

  • Up to 128 memory channels.

  • Dual PTT Key

  • CTCSS/ DCS

  • DTMF Code

  • LED Flashlight

  • Dual PTT Key

  • Dual Watch

  • Emergency Alarm

  • PC Programming

  • Cable replication

  • Call Tone 1750Hz

  • High/low voltage warning

  • Busy channel lockout

  • Scan

  • Dual standby channels Receive prompt function

Specifications

General

Frequency Range
VHF 144-148MHz & UHF 420-450MHz
Frequency Stability
±2.5ppm
Antenna High gain
Dual Band antenna
Antenna Impedance
50Ω
Operating Voltage
DC 7.4V
Mode of operation
Simple or semi-duplex
Dimension(W x H x D)
100 x 52 x 32 mm
Weight
250g(including battery, antenna)
Antenna
SMA -Female
Earpiece / mic type
Kenwood Plug type

 Transmitter
Output power
4W/1W (Max 5W)
Modulation Mode
16kΦF3E / 11kΦF3E
Maximum deviation
<5kHz(W) /<2.5kHz(N)
Intermediation distortion
 <10%
Adjacent Ch. power
≤-65dB(W) / ≤-60dB(N)
Pre-emphasis
6dB
Current
≤1.6A(5W)

Receiver

RF Sensitivity
-122dbm(12db SINAD)
Audio power
≥0.5W
Audio Distortion
≤10%
Intermediation
≤-65dB(Wide)/≤-60dB(Narrow)
Selectivity
≤-65dB(Wide)/≤-60dB(Narrow)
Spurious Rejection
≤-65dB
Blocking≥85dBuv/m

What's in  the box?

  • Walkie talkie

  • Li-Ion battery

  • Antenna

  • Belt Clip

  • User's Manual

  • Charger
