Mimosa N5-X12 Horn Antenna 12dBi

4.9-6.4 GHz Modular Twist-on Antenna, 70mm Horn for C5x only, 12 dBi gain

Features:

  • Four Twist-On, Flexible Antenna Options

  • PTP or PTMP Modes (feature key may be required)

  • Extended Frequency 4.9GHz – 6.4GHz

  • Best-in-Class Noise Immunity

  • Ultra Rugged

  • Low-Power Consumption

  • Ultra Reliable

  • Gigabit Ethernet: 10/100/1000-Base-T

  • Management Services: Mimosa cloud monitoring and management; SNMPv2 & Syslog monitoring; HTTPS; HTML5-based web UI


Product Introduction

Mimosa N5-X12 (100-00091) is the industry’s most versatile, modular, radio solution with five gain options (8, 12, 16, 20 and 25 dBi). The ultra-rugged solution provides extended frequency operation from 4.9–6.4 GHz, with best-in-class noise immunity. Delivering the ultimate in flexibility and value, the C5x is the go-to solution for 5 GHz deployments. Out of the box, the C5x can be used in PTMP mode, with Ethernet link speeds of up to 100 Mbps. With the purchase of a PTMP speed feature key, speeds of up to 500 Mbps will be unlocked in PTMP mode. In order to unlock and utilize PTP mode, with speeds of up to 700 Mbps, a PTP feature key must be purchased.



Features:

  • Four Twist-On, Flexible Antenna Options

  • PTP or PTMP Modes (feature key may be required)

  • Extended Frequency 4.9–6.4 GHz

  • Best-in-Class Noise Immunity

  • Ultra Rugged

  • Low-Power Consumption

  • Ultra Reliable

  • Gigabit Ethernet: 10/100/1000-Base-T

  • Management Services: Mimosa cloud monitoring and management; SNMPv2 & Syslog monitoring; HTTPS; HTML5-based web UI


Gain

12 dBi

Weight

0.16 kg (0.35 lbs)

Front-to-Back Ratio

29 dB

Front-to-Side Ratio

27 dB

Diameter

76 mm

Depth

67 mm

What's In The Box

One N5-X12 Horn
