OutBoard Engine 40 HP-4 Stroke Suzuki DF40ATL
Outboard Motor (OBM Engine)
Features
Multi Point Sequential Electronic Fuel Injection
Suzuki Lean burn Control System
Suzuki Troll Mode System
Direct Ignition
Suzuki Easy Start System
Over-Rev. Limiter
Low Oil Pressure Caution
Fully Transistorized Ignition
Timing Chain
Fresh Water Flushing System
Power Trim and Tilt
Suzuki Anti-Corrosion System
Introduction
This is the only engine in the 40 HP class to offer DOHC performance, and also the only engine in its class to incorporate a maintenance-free, oil-bathed timing chain, which provides the outboard with increased durability and maintenance free operation. With larger displacements for increased power and performance, Suzuki's Lean Control System for improved fuel economy and designs that are more compact and lighter in weight than the predecessor, the new DF40A engines also incorporate the Suzuki Troll Mode System. During the 2011 Miami Boat Show, the Boating Writers of America presented Suzuki Marine with the NMMA Innovation Award for the DF40A/DF50A.
Feature Highlights
High Performance DOHC 12-Valve Engine
Suzuki engineers based the DF50A and DF40A engine on Suzuki's proven in-line three-cylinder 12-valve engine. This high performance engine has a displacement of 941cm3 and features a DOHC powerhead—the only DOHC engine used in the 36.8kW (50PS)/29.4kW (40PS) outboard class—with four valves per cylinder, and an air intake system optimized for maximum efficiency in the high rpm range. When designing this engine, Suzuki engineers also focused on improving mechanical efficiency. Each component was analyzed and redesigned to reduce mechanical loss in order to improve efficiency. As an example, a new oil pump design makes internal oil flow more efficient, keeping moving parts better lubricated while using less energy. The combined reduction in mechanical loss throughout the engine contributes to better fuel economy
Suzuki's Lean Burn Control System
Suzuki's Lean Burn Control System is an intelligent system that monitors engine performance and operating conditions to predict fuel needs and deliver a leaner fuel mixture to the engine. First introduced on the DF90A/80A/70A, and later on the DF60A, this system provides remarkable improvements in fuel economy from low speed operation up into the cruising range, which is where the engine is used a majority of the time. In-house testing shows that at medium speeds, the DF50A achieves a 23% improvement in fuel consumption than its predecessor.
Multi-Point Sequential Electronic Fuel Injection
Suzuki pioneered the use of multi-point sequential electronic fuel injection in four-stroke outboards. This advanced, time-tested system gathers operating data from a series of sensors located in key areas on the engine, processes the data and calculates the optimum amount of fuel and air needed for the engine—all in real time. Boaters benefit with smooth starts, maximum operating efficiency, excellent fuel economy, and reduced emissions.
Maintenance Free Timing Chain
The DF50A and DF40A are the only outboards in the 36.8kW (50PS)/ 29.4kW (40PS) outboard class to incorporate a timing chain. The chain is oil-bathed, self adjusting, and maintenance free to provide boaters with years of dependable service.
Large Capacity 19A Alternator
The DF50A and DF40A are equipped with a powerful 19A alternator that generates approximately 11.5A even with the engine running at a low 1,000 rpm. Under normal circumstances that's enough power to keep an assortment of marine electronics operating in most situations.
When Only the Best is Good Enough
We are proud to be the sole supplier of marine outboard motors to the London 2012 Olympic & Paralympic Games Sailing Regatta, with the DF40A being one of the models used for this prestigious event.
Technology Used
POWERFUL
FUEL EFFICIENT
RELIABLE
INNOVATIVE
Mechanically Efficient DOHC 12-Valve Engine
Suzuki engineers based the DF50A and DF40A engine on Suzuki's proven in-line three-cylinder 12-valve engine. This high performance engine has a displacement of 941cm3 and features a DOHC powerhead—the only DOHC engine used in the 36.8kW (50PS)/29.4kW (40PS) outboard class—with four valves per cylinder, and an air intake system optimized for maximum efficiency in the high rpm range.
When designing this engine, Suzuki engineers also focused on improving mechanical efficiency. Each component was analyzed and redesigned to reduce mechanical loss in order to improve efficiency. As an example, a new oil pump design makes internal oil flow more efficient, keeping moving parts better lubricated while using less energy. The combined reduction in mechanical loss throughout the engine contributes to better fuel economy.
Suzuki Easy Start System
Starts are quick and easy with Suzuki's Easy Start System. No need to hold the key, just turn it once and the starter system stays engaged until the engine starts. The system delivers smoother and improved starts to get you up and running quicker.
Cleaner, Efficient Operation
Suzuki's advanced four-stroke technologies deliver clean and efficient outboard operation that conforms to EURO 1 Emissions Standards (EU Directive 2003/44/EC)—the EU emissions standards (exhaust gases and noise levels) set by the European Parliament and the Council, and have received three-star ratings from the California Air Resources Board (CARB).
Suzuki's Lean Burn Control System
Suzuki's Lean Burn Control System is an intelligent system that monitors engine performance and operating conditions to predict fuel needs and deliver a leaner fuel mixture to the engine. First introduced on the DF90A/80A/70A, and later on the DF60A, this system provides remarkable improvements in fuel economy from low speed operation up into the cruising range, which is where the engine is used a majority of the time. In-house testing shows that at medium speeds, the new DF50A achieves a 23% improvement in fuel consumption than its predecessor.
Maintenance Free Timing Chain
The DF50A and DF40A are the only outboards in the 36.8kW (50PS)/ 29.4kW (40PS) outboard class to incorporate a timing chain. The chain is oil-bathed, self adjusting, and maintenance free to provide boaters with years of dependable service.
Multi-Point Sequential Electronic Fuel Injection
Suzuki pioneered the use of multi-point sequential electronic fuel injection in four-stroke outboards. This advanced, time-tested system gathers operating data from a series of sensors located in key areas on the engine, processes the data and calculates the optimum amount of fuel and air needed for the engine—all in real time. Boaters benefit with smooth starts, maximum operating efficiency, excellent fuel economy, and reduced emissions.
Large capacity 19A Alternator
The DF50A and DF40A are equipped with a powerful 19A alternator that generates approximately 11.5A even with the engine running at a low 1,000 rpm. Under normal circumstances that's enough power to keep an assortment of marine electronics operating in most situations.
Suzuki's Anti Corrosion System
Suzuki protects the outboard's exterior from harmful corrosion with its own specially formulated anti-corrosion finish. Applying the finish directly to the outboard's aluminum surface, allows maximum bonding of the finish to the surface to increase durability and help protect parts that are constantly exposed to saltwater.
SPECIFICATIONS
| MODEL | DF40A |
| RECOMMENDED TRANSOM HEIGHT mm | S:381, L:508 |
| STARTING SYSTEM | Electric |
| WEIGHT kg *4 | S:102, L:104 |
| ENGINE TYPE | DOHC 12-Valve |
| FUEL DELIVERY SYSTEM | Multi-Point Sequential Electronic Fuel Injection |
| NO. OF CYLINDERS | 3 |
| PISTON DISPLACEMENT cm3 | 941 |
| BORE ×STROKE mm | 72.5 × 76 |
| MAXIMUM OUTPUT kW | 29.4 |
| FULL THROTTLE OPERATING RANGE rpm | 5,000-6,000 |
| STEERING | Remote |
| OIL PAN CAPACITY Lit. | 2.7 |
| FUEL TANK CAPACITY Lit. | 25 (Optional) |
| IGNITION SYSTEM | Fully-transistorized |
| ALTERNATOR | 12V 19A |
| ENGINE MOUNTING | Shear Mount |
| TRIM METHOD | Power Trim and Tilt |
| GEAR RATIO | 2.27:1 |
| GEAR SHIFT | F-N-R |
| EXHAUST | Through Prop Hub Exhaust |
| PROPELLER SELECTION | (Pitch) *5 |
| All propellers are the 3-blade type | 9"-17" |
